Satellite Station 4.0 Part 12 – Antenna Upgrades

Satellite Antennas On the Tower - Parked

Upgraded Satellite Antennas On the Tower

We’ve been making good use of our Satellite Ground Station. Our existing 2MCP14 and 436CP30 antennas have enabled us to make over 2,000 satellite contacts; working 49 of the 50 U.S. States, 290+ Grid Squares, and 31 DXCCs. Our station is also an ARISS Ground Station which enables us to help Schools around the world talk to astronauts on the ISS.

As you can tell, we are pretty active on Satellites so we decided to take our station up a level by upgrading our antennas. We choose the 2MCP22 and 436CP42UG antennas from M2 Antenna Systems with optional remote polarity switches. These are larger yagis with booms over 18+ ft in length. The upgrade required us to improve the mechanical aspects of our Satellite Antenna System as well.

Antenna Assembly

2MCP22 Parts Inventory

2MCP22 Parts Inventory

The first step in the project was to unpack and carefully inventory all of the parts for each antenna. This included carefully presorting and marking each element as we did during the assembly of our EME antennas.

2MCP22 Completed Antenna

2MCP22 Completed Antenna

The new antennas are quite large and they took most of the available space in our workshop during assembly. Getting good results from any antenna is all about attention to the details. Small things like turning the boom sections to get a good alignment of the elements, using NOALOX on the boom sections and hardware to prevent corrosion and galling, carefully measuring and centering the elements, etc. are all good things to do.

2MCP22 Feedpoint Assembly

2MCP22 Feedpoint Assembly including Polarity Switch Upgrade

The feedpoint system on these circular polarized antennas requires careful attention during assembly. It’s important to install drive element blocks, shorting bars, polarity switches, feedpoint splitters, and all phasing lines EXACTLY as shown in the antenna assembly manual. Failure to do these steps will likely results in SWR problems down the road.

436CP42UG Feedpoint Assembly

436CP42UG Feedpoint Assembly

The images above show the feedpoint assemblies for both of our new antennas.

New Satellite Yagis

New Satellite Yagis Ready For Installation

A rough SWR measurement with the antennas on the ground was performed to check for assembly errors. It’s a good idea to use a 12V battery to test the antenna SWR’s in both RHCP and LHCP. These tests checked out fine and we are ready to begin installing the antennas on our Tower.

Old Antenna Takedown and Work Stand

Old Antenna Assembly Takedown Using Boom Lift

Old Antenna Assembly Takedown Using Boom Lift

The next step in the installation was to take down our existing antennas. We rented a 50 ft Boom Lift for the project. The lift makes the work much easier and safer.

Old Antennas on Test Stand

Old Antennas on Test Stand

We have a ground tower that we use for portable satellite operations. It was fitted with a longer mast to create clearance for our larger antennas. We lowered the existing antenna system onto the ground tower for disassembly, installation, and testing of our new antennas.

It’s important to fully test a complex antenna system like this on the ground prior to installation on a Tower. We have routinely found and corrected problems this way. This approach also enabled us to properly adjust our cross boom and antenna support trusses and balance the final assembly properly. All of the required adjustments are MUCH easier with the antennas on the ground.

We also run our rotators under computer control for at least one full day before installing the completed assembly on our Tower. We have consistently found and corrected problems with cabling and balance this way.

Antenna Mounting and Trussing

2MCP22 Boom Truss

2MCP22 Boom Truss

The new antennas have very long booms (approximately 18 ft) and they have a tendency to sag. Add the ice and snow load that we experience here in New England and you end up with quite a bit of stress on the booms over time. Robert at M2 Antenna Systems came up with a custom truss assembly for our installation to address this problem. It’s important to minimize any metal in a setup like this to avoid distortion of the antenna patterns. The trusses use a solid fiberglass rod and small turnbuckles to support the ends of each antenna boom. There is much more weight on the rear of the booms due to the weight of the attached coax cables and polarity switches. For this reason, we located the truss anchor point for the rear of the boom such that it creates a sharper angle for the truss ropes at that end of the truss. This reduces the compression load on the rear of the boom and enables the truss to better carry the weight at the back of the antenna.

436CP42UG Boom Truss

436CP42UG Boom Truss

Installing a truss on the 70cm yagi is much trickier due to the tight pattern of this antenna. We minimized the added metal components by drilling the antenna boom to mount the truss plate directly to the boom via bolts.

We relocated the boom support plates on both antennas as far to the rear of the largest boom sections as possible to improve overall antenna balance. The clamps were also adjusted to change the orientation of the elements from vertical/horizontal to a 45-degree X arrangement. This maximizes the separation between the element tips and other metal components like the cross boom and truss plates.

Tubing Drill Guide

Tubing Drill Guide

All of this required drilling some new holes in our antenna booms. We used a Tubing Drill Guide and C-clamps to perform the required drilling operations accurately.

Satellite Antenna Boom Assembly

Satellite Antenna Boom Assembly

The photo above shows the new antennas mounted on our cross boom. The modification worked out great resulting in well supported and aligned antennas on the cross boom.

Balancing The Array

Cross Boom Counterweight and Trusses

Cross Boom Counterweight and Trusses

It’s very important to properly balance any antenna assembly that is used with an elevation rotator. Failure to do this will usually result in the failure of your elevation rotator in a short period of time. We initially had some pretty major balance problems with our new antennas. This is due, in part, to the weight of coax cables that run from the antenna feed points along the L-Brace Assemblies. The added weight of the Polarity Switches near the rear of the booms was also a significant contributor to this problem.

We created a counterweight by replacing one of our cross boom truss tubes with a metal section of pipe about 4 ft long. The pipe acts as a counterweight to the weight of the coaxes, etc.

Wheel Weights Used for Balancing

Wheel Weights Used for Balancing

Next, we added 4 1/2 pounds of weight to the front on the metal pipe. We used several layers of Wheel Weights built up in multiple layers to get the necessary counterweight. A heavy layer of electrical tape and some large cable ties were used to ensure that the weights say in place.

This got us close to a good balance but the boom of the 2MCP22 was still significantly out of balance. Matt at XX-Towers came up with a good solution to this problem. We added a few strips of wheel weights inside the very front of the boom of the 2MCP22 to finally get the antennas balanced. A combination of the adhesive tape on the weights and two small machine screws through the boom ensures that the weights remain in place and do not short the elements to the boom.

Finally, we adjusted our Green Heron RT-21 Az/El Rotator Controller to slow down the ramps for the rotator. Final testing indicated the smooth operation of the rotator at slow speeds.

SWR Testing and Baseline

2MCP22 Installed SWR

2MCP22 Installed SWR

A final check and baseline of all of our antennas were made on the ground. Both RCHP and LHCP modes were checked and recorded for future reference.

432CP42UG Installed SWR

432CP42UG Installed SWR

We found that some fine-tuning of the locations and routing of the phasing lines on our 436CP42UG improved the SWR curves. This is a common situation and it’s well worth the time to make small adjustments while carefully observing how they impact your SWR readings. The phasing cables are firmly secured to the antenna boom after the fine-tuning is complete.

New Antenna Installation and Integration on Tower

Upgraded Antennas Going On Tower

Upgraded Antennas Going On Tower

The next step in our project was to install the updated antenna assembly back on our Tower. We had to push the lower rotator and mast up about 4 ft to accommodate the larger antennas. We removed our 6M7JHVHD Yagi and temporarily fastened it to the side of our tower to make these steps easier. We also took the opportunity to work on our VHF Tower to adjust the length of the Driven Element on the 6M7JHVHD for better SWR performance in the FT8 and MSK144 section of the 6m band.

Satellite Tower Infrastructure and Accessories

Satellite Tower Infrastructure and Accessories

There is quite a bit of feed line and control cabling involved in a complex antenna system such as ours.

Control Cable Junction Box Internals

Control Cable Junction Box at the Base of VHF Tower

We use small junction boxes on our tower and a larger one at our tower base to make it easy to remote and reinstall all of the required control cables. Our approach was to hook up and test the rotators first to ensure that we did not have any new mechanical or balance problems. This step checked out fine. The stiffer chrome molly mast and its added length actually resulted in smoother operation of rotators than we saw during ground testing.

The final step was to work through the other control cables and feed line connections; testing each connection as we went. The Boom Lift makes this work much easier to do.

We took advantage of the availability of the Boom Lift and added some additional enhancements to our VHF Tower. Changing the battery in our Weather Station involved climbing our main tower to 50 ft. We moved the weather station to the 30 ft level on our VHF tower to make this maintenance step easier.

We also added an ADS-B antenna and feedline for the Raspberry Pi FlightAware tracker in our Shack. The parts used for the ADS-B antenna include:

You can view the statistics from our FlightAware Tracking station here. More on the FlightAware project to come in a future post.

Upgraded Antenna Performance

Satellite Antennas On the Tower - Tracking

Satellite Antennas On the Tower – Tracking

Initial testing of our new antennas is showing some major improvements. The uplink power required to work LEO satellites has been reduced significantly. As an example, I have worked stations using the RS-44 Linear Satellite with just 0.4 watts of uplink power out of our Satellite IC-9700. The signal reports we’ve received have been excellent as well.

More About Our Ground Station

Here are links to some additional posts about our Satellite Ground Stations:

Fred, AB1OC

EME Station 2.0 Part 13 – H-Frame Enhancements

Completed 2m EME Antenna System

Completed 2m EME Antenna System

Our new 2m EME Antenna System has been performing very well. One area that we noticed that could use improvement was the alignment of our antennas as we move them in the Elevation plane. The problem is caused by the weight of the coax feedlines running from the antenna feed points to the power dividers on our H-Frame assembly. Our H-Frame assembly includes T-Braces to support the coax feedlines but the T-Braces tended to bend and distort the alignment of our antennas as the Elevation Rotator is moved.

Custom EME H-Frame Truss System

Custom H-Frame Truss System

Matt at XX-Towers and Robert at M2 Antenna Systems helped us to come up with a very nice custom solution to solve these alignment problems. The solution consists of two additional truss cables on each of the H-Frame’s T-Brace assemblies. The truss cables are made from Phillystran Cable which is non-conductive and is adjusted via Turnbuckles that are anchored at the center of the H-Frame’s Vertical Risers. This approach minimizes any metal in locations that would affect the pattern of our antennas.

Cross Boom Extension

Cross Boom Extension

The first truss is mounted on a short custom extension on each end of our H-Frame’s Cross Boom and is run to an eye bolt in the center of each T-Brace Vertical Rod.

T-Brace Main Truss

T-Brace Main Truss

These risers stabilize the tendency for the T-Brace Vertical Assembly to flex and move towards the center of the H-Frame when the full weight of the coax cables are bearing on them at various elevation angles. Careful adjustment of the combination of these new Truss Cables and the existing 45-degree T-Brace Horizontal Support Assemblies results in the rear of each antenna boom staying perfectly aligned as we rotate our antennas in elevation.

T-Brace Rear Truss

T-Brace Rear Truss

The other problem that our custom Truss Solution addresses is the tendency for the weight of the coax cables to bend the rear of the antenna booms down when the antennas are at 0-degrees in elevation. The bending is due to the weight of the coax cables on the T-brace being unsupported and bearing down on the rear of the antenna booms. This problem is solved by a second Phillystran truss cable that runs from the metal section of each Vertical Riser assembly to the junction between the rear of the bottom antenna booms and the associated junction of the Vertical T-Brace Assemblies.

We fastened the Phillystan cables directly to the junction point without the use of any metal hardware to ensure that the pattern of our antennas was not affected. These secondary Trusses now carry all of the weight of the coax cables on the T-brace as the antennas approach at 0-degrees in elevation and have eliminated the bending at the rear of our antenna booms.

With these modifications, our antennas remain perfectly aligned at any elevation angle. There is also noticeably less stress on the fiberglass sections of the Vertical Riser Assemblies since they are no longer carrying the load of the coax cables.

Next Steps

We have a dual-channel coherent SDR receiver from Afedri in hand which will allow us to do Adaptive Polarity using MAP65. We will be upgrading our station hardware and software to support Adaptive Polarity in the near future.

Our initial experience with operating our new 2m EME station will be covered in the next article in this series.

You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Tech Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

EME Station 2.0 Part 12 – Station Software

EME Operating Position

EME Operating Position

Software is a big part of most current EME stations. The JT65 Protocol, which was created by Joe Taylor, K1JT, has revolutionized EME operations. It has made it possible for modest single and two yagi stations to have lots of fun with EME.

Phase 1 of our 2m EME station software and hardware uses manual switching/selection of receive polarity. This Phase is about integrating all of the station components together and sorting out operational issues. After some experimentation, we have settled on a dual-decoder architecture for the First Phase of our 2m EME Station.

You can learn more about the Phase 1 EME hardware setup at our station here.

EME Software Environment

EME Station Block Diagram - Phase 1

EME Station Block Diagram – Phase 1

The diagram above shows the current configuration of our 2m EME station. As explained in a previous article in this series, we are using a FUNCube Pro+ Dongle with the MAP65 application as our primary JT65b decoder and we are using our IC-9700 Transceiver along with WSJT-X as a secondary, averaging decoder. Using multiple decoders has proven to be a significant advantage. It is quite common for one of the two applications to decode a weak signal that the other does not.

We use two custom applications (WSJTBridge and Flex-Bridge) to capture the Moon Azimuth and Elevation data generated by the MAP65 application and use it to control the rotators for our EME Antenna Array.

We have been experimenting with Linrad as a front-end to MAP65 and WSJT-X. At present, we are using the NB/NR functions in MAP65 and in our IC-9700 as an alternative to Linrad. We expect the add Linrad into our setup when we add Adaptive Polarity capabilities in Phase 2.

EME Software Operating Environment

EME Software Operating Environment (click for a larger view)

We use the DXLab Suite for logging and QSL’ing our contacts along with several web apps to find potential EME contacts and to determine the level of EME Degradation on any given day.

The screenshot above shows most of these apps running during a 2m EME operating session.

MAP65 Application – Primary Decoder and Operating Application

MAP65 Software

MAP65 Software

We are using MAP65 as our primary decoder. It also controls our IC-9700 Transceiver when transmitting JT65b messages. MAP65 used the I/Q data from our FUNCube Pro+ Dongle to detect and decode all of the signals in the 2m EME sub-band. A waterfall window displays all of the signals on the band as well as a zoomed-in view of the spectrum around the current QSO frequency. MAP65 also generates heading data for our rotators as well as estimates for the doppler shift between stations. The MAP65 application also provides windows that list all of the stations on the band as well as the messages that they are sending.

EME QSOs via MAP65

EME QSOs via MAP65

The screenshot above shows the main MAP65 window during a QSO with HB9Q. Round trip delay (DT) and signal strength information (dB) is shown for each message that is decoded. The MAP65 application along with a manual that explains how to set up and use the program for 2m EME can be downloaded here.

Moon Tracking and Rotator Control

Custom Rotator Control Apps

Custom Rotator Control Apps (WSJT-Bridge and FlexBridge)

We developed an application we call FlexBridge some time back as part of our ongoing project to remote our Satellite Ground Station using our Flex-6700 based SDR Remote Operating Gateway. This application includes functionality to operate Az/El rotator controllers based upon UDP messages which contain tracking data. We wrote a second application that we call WSJT-Bridge which reads the Moon heading data that either MAP65 or WSJT-X and generates and sends UDP messages that enable FlexBridge to track the moon. The combination enables MAP65 to control tracking the moon in our setup.

Both of these applications are at an alpha stage and we will probably separate the rotator control functionality from FlexBridge and make it into a dedicated application.

Antennas On The Moon

Antennas On The Moon

One of the first steps in the integration process was to carefully calibrate our rotators to point precisely at the moon. We got the azimuth calibration close using the K1FO Beacon in CT. With this done, we made final adjustments visually until our antennas were centered on the moon on a clear night.

EME Tower Camera at Night

EME Tower Camera at Night

We recently installed an additional IP camera which gives us a view of our EME tower. This is a useful capability as it enables us to confirm the operation of our rotator from our shack.

WSJT-X – Secondary Decoder

WSJT-X Software

WSJT-X Software

We also run WSJT-X as a second decoder using the receive audio stream from our IC-9700 Transceiver. WSJT-X has some more advanced decoding functions and can average several sequences of JT65b 50-second transmissions to improve decoding sensitivity. It only works on one specific frequency at a time so we use it to complement the broadband decoding capability that MAP65 provides.

We can also transmit using WSJT-X which enables us to use its Echo Test functionality to confirm that we can receive our own signals off the moon.

The WSJT-X application along with a manual that explains how to set up and use the program for EME can be downloaded here.

Finding Contacts and Logging

Finding QSOs and Logging

Finding Contacts and Logging

We use the DXLab Suite for logging and QSL’ing our contacts. DXLab’s Commander application provides the interface between WSJT-X and our IC-9700 Transceiver. This enables the DXLab Suite to determine the current QSO frequency and mode for logging purposes.

MAP65 Software

MAP65 Software and DXKeeper’s Capture Window

We keep DXKeeper’s Capture Window open on the screen where we run MAP65 so we can easily transfer QSO information to our log as we make contacts.

We also use several web apps to find potential EME contacts and to get an estimate of the level of EME Degradation on any given day:

We are working on interfacing our instance of MAP65 to LiveCQ so that we can contribute spots when we are operating. More on this to come in a future article in this series.

Next Steps

We have a dual-channel coherent SDR receiver from Afedri in hand which will allow us to do Adaptive Polarity using MAP65. We will be upgrading our station hardware and software to support Adaptive Polarity in the near future.

We are planning some enhancements to our H-Frame to enable better alignment of our antennas along with improved reliability and stability when rotator our antennas. We will cover these enhancements in the next article in this series.

You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Tech Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

EME Station 2.0 Part 11 – Station Hardware In Shack

EME Station Hardware Components

EME and Satellite Ground Station Hardware Components

Now that our 2m EME Antenna Array is fully installed, we have turned our attention to the setup of the equipment in our Shack. Our plan is to do a mix of JT65 Digital and CW operation with our 2m EME Station.

The image above shows the equipment that is dedicated to EME and Satellite operations in our station. We built some shelves to make room for all of the equipment as well as to create some space to move our Satellite Ground Station 4.0 to this same area. The components in our 2m EME station include (left to right):

We’ll explain each of these components as well as the supporting shack infrastructure that we are using for EME below.

Phase 1 Station Architecture

EME Station Block Diagram - Phase 1

EME Station Block Diagram – Phase 1 (Manual Rx Polarity Selection)

Unfortunately, the LinkRF Receiver and Sound Card to enable a full MAP65 Adaptive Polarity installation are not currently available. As a result, we’ve created a Phase I Architecture that uses an SDR Dongle and manual selection of Receive Polarity via a switch. We also added a receive splitter and a Transmit/Receive relay in front of an Icom IC-9700 Transceiver which is dedicated to our EME setup to enable both the MAP65 and one of either the WSJT10 or WSJT-X Software Decoders to operate simultaneously.

This approach has some significant advantages when conditions are poor as one of either MAP65 or WSJT10/WSJT-X will often decode a marginal signal when the other will not. More on this in the next article in this series which will explain the software we are using more.

Transceiver, SDR Receiver, and Sequencing

IC-9700 Transceiver and Sequencer

IC-9700 Transceiver and Sequencer

A combination of an Icom IC-9700 Transceiver and M2 Antennas S2 Sequencer handle the Transmit side of our EME Station including the associated sequencing of the preamplifiers and Transmit/Receive Switching which is part of our Antenna System. The IC-9700’s receiver is also used with the WSJT10 Decoder in our setup.

GDSO Injection Board Installed in IC-9700

Reference Injection Board Installed in IC-9700 (Leo Bodnar Website)

To ensure good frequency stability in our setup, we installed a Reference Injection Board from Leo Bodnar in our IC-9700.  The Reference Injection Board uses Leo Bodnar’s Mini Precision GPS Reference Clock (the small device on top of our IC-9700 in the photo above) to lock the IC-9700 to a highly accurate GPS sourced clock. The installation and configuration of the Reference Injection Board in our IC-9700 were simple and Leo Bodnar’s website covers the installation and setup procedure for these components. FUNcube Dongle Pro+

FUNcube Dongle Pro+

We used a FUNcube Dongle Pro+ as a second Software Defined Radio (SDR) Receiver in our setup and as an I/Q source to drive the MAP65 Software. Good information on configuring the MAP65 software to work with this dongle can be found here.

EME Station RF Paths and Sequencing

EME Station RF Paths and Sequencing

The diagram above shows the RF Paths and associated sequencing in our Version 1 EME Station. A Manual Antenna Switch is used to select either Horizontal or Vertical polarity when in receive mode. The S2 Sequencer handles polarity selection during transmit. A splitter divides the Rx signal between the FUNcube Pro+ Dongle for MAP65 and a Transmit/Receive Switching Circuit in front of our IC-9700 Transceiver. The relay enables the IC-9700 to provide Transmit signals for both the MAP65 and WSJT10/WSJT-X Software applications. The IC-9700 drives a 1.2 Kw Amplifier during Transmit and the final Tx output is metered using a WaveNode WN-2 Wattmeter.

Completed T/R Relay Assembly

Completed T/R Relay Assembly

To enable both the receivers in our IC-9700 and the FUNcube Dongle to function simultaneously, we built a circuit using a CX800N DPDT RF Relay and a Mini-Circuits 2-Way RF Splitter. We also built a simple driver circuit for the relay using a Darlington Power Transistor and some protection diodes. The circuit enabled our S2 Sequencer to control the relay along with the rest of the sequencing required when changing our EME Station from Receive to Transmit and back.

Finally, we configured a 30mS transmit delay in our IC-9700 to ensure that the S2 Sequencer had some time to do its job as the station transitions from Receive to Transmit. This delay coupled with the Transmit delays built into the MAP65 and WSJT10 software ensures that we will not hot switch the MAP65 Preamp System on our tower. One must be very careful to ensure that RF power is not applied before the sequencer can complete its transition to the Transmit state or damage to the Preamplifiers and/or relays at the tower will occur.

Amplifier and Rotator Controls

EME Station Hardware Components

EME and Satellite Ground Station Hardware Components

The Elevation Rotator from our Antenna System was added to the Green Heron RT-21 Az/El Rotator Controller previously installed in our shack and both the Azimuth and Elevation Rotators were roughly calibrated. Our EME station requires quite a few USB connections to our Windows 10 Computer so we added a powered USB hub to our setup. Chokes were added to the USB cables which run to our IC-9700 Transceiver and our FUNcube Dongle to minimize digital noise from getting into our receivers.

Our planned OM Power 2002+ Amplifier is not yet available so we temporarily moved our M2 Antennas 2M-1K2 Amplifier from our Terrestrial Weak Signal setup to our EME station. The 2M-1K2 can produce about 1KW of power on 2m when operating in JT65 mode and this should be enough power for our planned EME work until the OM Power Amplifier is available. Our S2 Sequencer also controls the keying of our Amplifier as part of the T/R changeover sequence in our EME station.

WaveNode WN-2 Wattmeter

WaveNode WN-2 Wattmeter

We added a 2m high power sensor to the output of our Amplifier and connected it to a free port on one of the WaveNode WN-2 Wattmeters in our station to provide output and SWR monitoring of the Transmit output of our EME station.

Supporting Station Infrastructure

VHF+ Antenna Switching Console

VHF+ Antenna Switching Console

We had some work to do to configure the antenna, grounding, and DC power infrastructure in our station. We redid the manual switching in our VHF/UHF Antenna Switching consoles to accommodate our new EME Antenna System as well as to prepare for our Satellite Station to be moved into our shack in the near future. The console on the right provides Grounding of the Transmit and Receive sides of our EME Antenna System as well as the selection of the Antenna’s Horizontal or Vertical polarity for decoding.

We also expanded our station grounding system to provide a ground point directly behind all of our EME equipment. Our DC power system was also expanded to accommodate our EME equipment.

GPS NTP Server

GPS NTP Server

Our station already has a GPS Controlled NTP Time Server installed and we’ll use it to ensure that the clock on the PC which will run the MAP65 and WSJT10 software will have very accurate clocks for JT65 decoding.

EME Tower CAM

EME Tower CAM

We already have cameras that cover our Main and Satellite Towers. We’ve added a third camera to allow us to view our EME Tower’s operation from our shack. This ensures that we can visually confirm the operation of our antennas and detect any problems should they occur.

Next Steps

All of the new EME equipment has to be integrated and tested with the software components which provide digital operation, tracking of the moon, logging, and other functions in our station. The software setup as well as our initial experience with operating our new EME station will be covered in the next article in this series.

You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Tech Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

EME Station 2.0 Part 10 – Antennas On The Tower

Completed 2m EME Antenna System

After a year’s worth of planning and 10 months of construction, we have our new 2m EME Antenna System installed on our EME Tower and working! This stage of our project took about a week and included a lot of help from Matt and Andrew at XX Towers.

Final Preparations

Antenna Ground Test

The first step was to arrange the four 2MXP28 Yagis that we built on saw horses near our EME Tower and check each antenna’s vertical and horizontal SWR. Performing SWR measurements with the antennas close to the ground like this does not produce very accurate measurements. Doing this does allow one to spot potential problems if some of the measured SWR fail to show a resonance or are wildly different than the other antennas in the group. All of our antennas checked out as expected.

50 Ft Boom Lift, H-Frame Cross Boom Assembly On The Ground

We also rented a 50-ft Boom Lift and set it up near our EME Tower. A tool like this is almost essential to safely assemble and adjust a large, complex antenna system involving an H-Frame. It also speeds up the assembly and adjustment process considerably.

Elevation Rotator and H-Frame

Elevation Rotator Installation on Mast

Elevation Rotator Installation on Mast

The first step was to install the MT-3000A Elevation Rotator on the mast. We pre-installed the control cable for the elevation rotator before installing it on the tower. This enabled us to get it temporarily hooked up to the Rotator Controller in our shack so that we could adjust the elevation of the H-Frame and Antennas as we installed them.

H-Frame Assembly on Tower

H-Frame Assembly on Tower

Next, Matt and Andrew installed the H-Frame Crossboom and Truss assembly on the Elevation Rotator. The assembled Vertical Risers went on next to complete the H-frame. The time spent pre-assembling these components and marking centers to enable accurate final assembly saved a great deal of time.

Antenna Installation

Upper Antenna Installation

Upper Antenna Installation

With the H-Frame in place, we installed the upper 2MXP28 Yagi Antennas next. The image above shows the rigging of the boom trusses which was done on the Tower.

Lower Antenna Installation and Adjustments

Lower Antenna Installation and Adjustments

Next came the lower 2MXP28 Yagis. We spent considerable time leveling and aligning all of the Antennas and H-Frame components at this stage.

Feedlines, Electronics, and Balancing

T-Braces and Feedlines

T-Braces and Feedlines

The T-Brace assemblies and Antenna Phasing Lines were installed next. Each Antenna requires two LMR-400 Phasing Lines and these coax cables add considerable weight to the backs of the Antennas. The T-Braces support these cables and help to align the Antennas on the H-Frame.

We replaced the Vertical H-Frame Boom Truss Pipe with a heavy section of Mast Pipe to act as a counter-weight and balance the final H-Frame and Antenna assembly. This step is critical to ensuring a long life for the Elevation Rotator’s drive system and chain.

Phasing Lines, Power Dividers, and Feedline Connections on Crossboom

Phasing Lines, Power Dividers, and Feedline Connections on Crossboom

The photo above shows the final installation of the Power Dividers, Antenna Phasing Lines (there are 8 in total), the MAP65 Preamp Housing, and the Feed and Control Cables that run down the Tower. We took the time to carefully make SWR measurements on each Antenna and check all of the connections to the MAP65 Housing at this stage.

Antenna Integration Details

Rotator Loop

Rotator Loop

The Rotator Loop contains the following cables and Coax Feedline connections from the H-Frame/Antenna assembly:

  • Vertical and Horizontal Rx Feedlines
  • Tx Feedline
  • Elevation Rotator Control Cable
  • MAP65 Housing Control Cable

All of these cables are bundled and securely fastened to the H-Frame Cross Boom and to the Tower. Andrew is a master at this sort of rigging!

Control Cable Connections at Tower Base

Control Cable Connections at Tower Base

I took some time to finalize the Control Cable connections at the base of our tower. Time was spent with a voltmeter doing checks to ensure that everything was connected correctly and working. This effort resulted in the discovery and correction of some wiring errors and a faulty relay in the MAP65 housing. Had I not done these steps, we would have surely destroyed the Preamps in the MAP65 Housing when we transmitted for the first time.

Testing Our New Antenna System

Vertical Polarity Tx SWR at Shack

Vertical Polarity Tx SWR at Shack

A series of SWR measurements were taken before sealing the coax cable connections on the tower. SWR measurements were checked and recorded for future reference at the following points in the feedline system:

  • At the ends of the phasing lines associated with each antenna
  • At the output of the two Power Dividers on the tower
  • At the shack entry ground block

Measurements were taken separately for both the Vertical and Horizontal elements of the final Antenna System. The image above shows a typical SWR measurement for our final Antenna System.

I did many final checks and adjustments while the Boom Lift was still here. These steps included:

  • Checking the oil level in the elevation rotator
  • Re-lubing the elevation rotator chain
  • Adjusting the limit switch stops on the Elevation Rotator to allow enough over-travel for future adjustments and maintenance
  • Checking all hardware for tightness
  • Sealing all coax cable connectors with Coax Wrap and Electrical Tape
  • Making some final adjustments to align the four 2MXP28 Antennas with each other and the H-Frame

Next Steps

The next step in our project will be the integration of our new 2m EME Antenna System into our shack. This step will include the final setup, configuration, and testing of the Rotator Controller, Interim SDR Receiver, Transmitter, Amplifier, and the MAP65 and Moon Tracking Software.

You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Tech Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

ISS Voice Repeater is QRV!

International Space Station (ISS)

International Space Station (ISS)

Thanks to some great work by the ARISS Team, a new Voice Repeater system is operating on the International Space Station! Here is the access information:

  • Mode: FM Voice
  • Uplink Frequency: 145.990 MHz, PL 67.0 Hz
  • Downlink Frequency: 437.800 MHz
IORS Hardware

IORS Hardware and Kenwood Radio

The repeater uses the new InterOperable Radio System (IORS), a space-modified JVC Kenwood D710GA transceiver, and an ARISS developed power supply system.

Kenwood D710GA

Kenwood D710GA

Here’s some more information from the ARISS Press Release:

The ARISS team is pleased to announce that the setup and installation of the first element of our next-generation radio system was completed and amateur radio operations with it are now underway. This first element, dubbed the InterOperable Radio System (IORS), was installed in the International Space Station Columbus module. The IORS replaces the Ericsson radio system and packet module that were originally certified for spaceflight on July 26, 2000.

The initial operation of the new radio system is in FM cross-band repeater mode using an uplink frequency of 145.99 MHz with an access tone of 67 Hz and a downlink frequency of 437.800 MHz. System activation was first observed at 01:02 UTC on September 2. Special operations will continue to be announced.

The IORS was launched from Kennedy Space Center on March 6, 2020, on board the SpaceX CRS-20 resupply mission. It consists of a special, space-modified JVC Kenwood D710GA transceiver, an ARISS developed multi-voltage power supply, and interconnecting cables. The design, development, fabrication, testing, and launch of the first IORS was an incredible five-year engineering achievement accomplished by the ARISS hardware volunteer team. It will enable new, exciting capabilities for ham radio operators, students, and the general public. Capabilities include a higher power radio, voice repeater, digital packet radio (APRS) capabilities, and a Kenwood VC-H1 slow-scan television (SSTV) system…

You can view the full ARISS Press Release here.

I was able to work several stations using the new ISS Voice Repeater this morning. It is very sensitive and uses 5 watts of downlink power with a good antenna on the ISS. I was able to make solid contacts using the Ground Station here using only 1.5 watts uplink power when the ISS was at 10 degrees above the horizon. At least one of my contacts was with a station using an HT with a whip antenna!

The voice repeater is sensitive enough and uses a power level that will enable folks with an HT and a whip antenna to make contacts using the ISS when it is close to the horizon. It should also be easy to make contacts using mobile rigs that can support cross-band operation as well. Program your radios!

I’m looking forward to working you through the ISS!

Fred, AB1OC



EME Station 2.0 Part 9 – H-Frame Assembly

M2 Antennas 2X2 2MXP28-32 H-Frame

M2 Antennas 2X2 2MXP28-32 H-Frame

The final major component to be assembled is the 2MXP28-32-2X2-3K H-Frame which will support our four 2MXP28 Antennas. The H-Frame is one of the most mechanically complex components in our EME antenna system so we began by carefully studying M2’s manual for this component.

Parts Identification, Inventory, and Preparation

H-Frame Parts Inventory

H-Frame Parts Inventory

We also spent some time identifying and inventorying all of the parts. M2 supplied upgraded aluminum saddle clamps for our H-Frame. These parts improve the clamping action between the components and also reduce stresses on the fiberglass and other tube parts.

Truss Cable Parts Prep

Truss Cable Parts Prep

We spent some time preparing the parts for the Phillystran Truss cables for the Main Cross Boom and Vertical Risers. Prep included a drop of oil on each of the clamp threads and some NOALOX Antioxidant Compound on the turnbuckle threads. We also added stainless steel jam nuts to the turnbuckles to lock them in place after installation.

Initial Assembly of H-Frame Sections

Assembled H-Frame Sections

Assembled H-Frame Sections

We next mock-ed up the center section of the 3″ Main Cross Boom in the Elevation Rotator assembly to ensure proper fit and operation of the Elevation Rotator.

With this done, we assembled the Main Cross Boom, Vertical Risers, and T-Brace sections. This helped us to get all of the parts and hardware in the correct locations and to become familiar with how all of the parts fit together. We used a generous coat of NOALOX on all of the metal to metal tubing joints to facilitate the assembly and to prevent corrosion from forming at the joints of the metal tube sections. This sort of corrosion can cause increased noise levels after the array is installed outdoors for some time.

Main Crossboom Assembly

Cross Boom Truss Assembly

Cross Boom Truss Assembly

Next, the 3″ Main Cross Boom and its support Trusses were assembled. We carefully measured the assembly and marked the center as well as the locations of the Vertical Risers on the Main Cross Boom using a sharpie pen. these measurements will make the final assembly of the H-Frame on our Tower much easier.

Cross Boom Truss Details

Cross Boom Truss Details

The Phillystran Truss Cables and associated hardware were assembled and adjusted next.

Vertical Riser Assembly

Vertical Riser Mock-up

Vertical Riser Mock-up

We decided to Mock-up a section of the Vertical Riser center tubes and the associated Vertical Riser Truss supports on the Main Cross Boom. This allowed us to confirm that the final horizontal spacing of the Risers was correct and to get the clamps associated with this part of the H-Frame assembly properly oriented and squared.

Fiberglass Tubing Reinforcements

Reinforcement Bushing Design

Reinforcement Bushing Design

The Vertical Risers use fiberglass tubes at each end to provide a non-conductive mast for mounting the Antennas and their Truss Supports. The Antennas we are using are large and will need to be tightly clamped to ensure that they stay aligned and in place. The Antenna and associated Truss U-clamps put a great deal of stress on the fiberglass tubes and they can become distorted or damaged over time.

To prevent this, we decided to make a custom set of reinforcement bushings from polycarbonate plastic. Bushings were designed to reinforce all of the points on the fiberglass tubes of both Vertical Risers where U-Clamps will be used. You can see the full set of specifications for the bushings here.

W2SW Custom Reinforcement Bushings

W2SW Custom Reinforcement Bushings

Spencer, W2SW, owner, and founder of AntennaSys, Inc. made a beautiful set of custom bushings for us. Spencer has an amazing machine shop at his home and the parts turned out great and fitted precisely.

Reinforcement Bushing Installation

Reinforcement Bushing Installation

The reinforcement bushings were installed at the correct depth in each of the Fiberglass Tubes and are pinned in place using small stainless steel machine screws.

One consequence of installing the reinforcement bushings is that water can accumulate in the fiberglass tubes if they are in a horizontal position for a period of time. If such accumulated water freezes, it could cause damage to the tubes. This problem is easily solved by drilling a series of small 1/8-inch drain holes in the tubes on the bottom side when they are horizontal.

Assembled Vertical Riser

Assembled Vertical Riser

The final step was to assemble all of the parts associated with both Vertical Risers. The risers were marked to indicate the location of each Antenna Boom and Truss Clamp and the clamps were installed. The Phillystran Truss Cables were installed in the Eye Bolts on the Vertical Risers.

As we did with the Antenna Truss Cables, we will wait to install the turnbuckles until the Vertical Risers are installed on the tower and balanced. This will likely change the length of the Phillystran Truss cables.

Next Steps

The next step in our project will be the installation of our Elevation Rotator, H-Frame, Antennas, Power Dividers, MAP65 Housing, and Phasing Lines on our EME Tower. You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Teach Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

EME Station 2.0 Part 8 – Elevation Rotator Assembly and Sub-System Test

Elevation Rotator and MAP65 EME Preamp System Test

The next major component in our new EME station is the assembly of the Elevation Rotator. This step also involves pre-assembly and testing of the MAP65 Pre-amp Housing, Antenna Power Dividers, Transmit/Receive Sequencer, and the Rotator Controller. Here are the components involved in this part of our project:

We choose the MT-3000A Elevation Rotator for its heavy-duty construction. This will be important to handle the weight of our EME antenna array as well as the winter conditions that we encounter here in New England.

Elevation Rotator Assembly

MT-3000A Elevation Rotator Parts

MT-3000A Elevation Rotator Parts

The first step was to inventory all of the parts for the MT-3000A Elevation Rotator and carefully read the MT-3000A manual from M2 Antennas.

Assembled MT-3000A Elevation Rotator

Assembled MT-3000A Elevation Rotator

Assembly of the MT-3000A is pretty straight forward. It uses a chain-drive system to produce a very strong, high-torque elevation rotator system. It’s important to fill the gear-box with the supplied gear oil and to lube the chain with the proper lubricant prior to testing and installing the rotator. Spray style chain lubricants for motorcycle chains work well in this application.

Rotator Controller Integration and Testing

Green Heron RT-21 Az-El Rotator Controller

Green Heron RT-21 Az-El Rotator Controller

The next step was to make up a rotator and connect the MT-3000A to our Green Heron RT-21 Az/El Rotator Controller for a test. The RT-21 Az/El is a very flexible controller that is capable of controlling almost any popular antenna rotator. We’ve already tested this unit with the M2 Antennas OR2800G2 Azimuth Rotator that is installed on our EME tower.

RT-21 Configuration of the MT-3000A Elevation Rotator

RT-21 Configuration of the MT-3000A Elevation Rotator

The MT-3000A is a pulse-counter style rotator with 0.1-degree positioning resolution. It required a custom setup in the Green Heron RT-21 Az/El which was easily accomplished with Green Heron Engineering’s setup utility. One must determine the correct Divide Ratio setting by experimentation. When the correct value is found, a rotation of 90 degrees on the controller will result in exactly 90 degrees of actual movement by the MT-3000A. This calibration was much easier to do with the MT-3000A in our shop than it would have been once the unit was installed on our tower. We also set up the RT-21 Az/El Controller to allow for 5 degrees of rotation beyond the 0 and 90-degree points.

After some testing, I decided to use the 42Vdc tap setting in the RT-21 Elevation Controller with our MT-3000A. The specifications for the MT-3000A allow for up to 42 Vdc to be used to run its motor. To be safe, we set the Max Speed setting in the RT-21 Az/El to “8” which resulted in a maximum of 40 Vdc measured with a voltmeter at the output of the controller.

Assembly and Integration of MAP65 Housing and Cross Boom

Elevation Rotator and MAP65 Preamp Housing Assembly

Elevation Rotator and MAP65 Preamp Housing Assembly

The next step was to install the H-frame Main Boom center section and Truss Support Tubes in the MT-3000A. The MAP65 EME Preamp Housing is mounted on the horizontal Truss Support Tube as shown above.

MAP65 EME Preamp System Housing

MAP65 EME Preamp System Housing

A control cable for the MAP65 EME Preamp Housing was made up and connected to the terminal strip on the housing.

EME Sequencer Testing

S2 Sequencer

S2 Sequencer

The S2 EME Sequencer from M2 Antennas is designed to control the MAP65 Housing but its internal jumpers must be properly set to do this. We spent some time with the manual for the S2 Sequencer and for the MAP65 Housing carefully setting the S2 Sequencer’s jumpers and verifying proper voltages at both the output of the S2 Sequencer and the terminal strip in the MAP65 housing with a voltmeter. The manuals for the S2 EME Sequencer and the MAP65 EME Preamp Housing were clear on these steps.

Mounting Power Dividers

Power Divider Mounting Bracket

Power Divider Mounting Bracket

The next step in this part of our project was to mount the M2 Antennas 4-Port Power Dividers that are used to connect the MAP65 Pre-Amp housing to the four 2MXP28 Antennas. Two power dividers are required as each antenna has a separate feed point connection for their horizontal and vertical polarities. We made up some custom mounting brackets for the power dividers from 1-1/4″ aluminum angle material.

MAP65 EME Preamp Housing Connections

MAP65 EME Preamp Housing Connections

The MAP65 Preamp Housing connects to the outputs of the two Power Dividers that feed the H-polarity and V-polarity of the antenna array. The outputs from the MAP65 EME Housing connect to the H-polarity and V-polarity receive coax cables and the Transmit Hardline Coax Cable that runs from the tower to our shack.

Coax Interconnect Cables

Power Divider and Feedline Jumper Coax Cables

Power Divider and Feedline Jumper Coax Cables

The final step was to make up LMR-400 coax cables to connect the MAP65 Preamp Housing to the Power Dividers. We used right-angle male N connectors to make the connections to the 4-Port power drivers to avoid sharp bends in the cables.

We also made up three additional LMR-400uF coax cables to connect the MAP65 Preamp Housing to the coax Tx and Rx feedlines that are installed on our tower. It’s important to keep the H-Pol and V-Pol cables as close to identical in length as possible to minimize and phase differences between the associated receive feedline systems.

Next Steps

The next step in our project will be the final assembly and preparation of the H-frame which will be used to mount our four 2MXP28 Antennas. You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Teach Night on this topic. You can find the EME Tech Night here.

Fred – AB1OC

EME Station 2.0 Part 7 – Building Antennas

M2 Antennas 2MXP28 X-Pol Yagi

M2 Antennas 2MXP28 X-Pol Yagi

The next step in our EME project is to assemble the four M2 Antenna Systems 2MXP28 Yagis. These antennas are large, cross-polarized yagis. They feature 28 elements each on 34 1/2 foot booms. The design operates as an independent horizontal and vertical Yagi on a shared boom and each plane have an independent feed point.

EME Antenna Array Assembly

EME Antenna Array Assembly on H-Frame

We are building four of these antennas to be mounted on an M2 Antennas 2X2 H-Frame. It is important that the four antennas be identical so they operate properly as an array. This includes things like symmetrical mounting and alignment of each antenna’s vertical and horizontal elements and the associated feed points. We will cover the assembly of the H-frame and Elevation Rotator systems in the next article.

Preparation

NOALOX Assembly Compound and Sharpie Pen

NOALOX Assembly Compound and Sharpie Pen

M2 Antenna Systems instruction manuals are very good and they specify the tools and procedures to properly assemble the associated antennas. A few additional items were helpful in our project. These included:

The assembly steps and procedures are similar for most M2 Antennas 2m and UHF Yagi antennas so I’m going to share some details and a few tricks that we’ve used successfully to build a number of their Yagis. You can see some of these other projects via the following links:

We successfully built all of these antennas using similar components and techniques.

M2XP28 Sorted Parts

M2XP28 Yagi Sorted Parts

The first step in assembling each antenna was to inventory and arrange all of the parts. I also took the time to wipe the boom elements with a solvent soaked cloth to remove dirt and aluminum dust that results from the manufacturing process. This makes assembling the antenna a much cleaner process.

2MXP28 Yagi Dimension Sheet

2MXP28 Yagi Dimension Sheet

M2 supplies detailed dimension sheets and boom layout diagrams with their antennas and we took the time to carefully identify each element and boom component according to the diagrams.

Element Measurement and Marking

Element Measurement and Marking

This step included careful measuring, sorting, and marking each element with its location and polarity (horizontal or vertical). This step makes the somewhat difficult step of getting all of the elements in the correct polarity and orders much easier. The marks allowed me to check and confirm the correct installation of all of the elements on the antenna boom before locking them in place.

Mast Clamp and Boom Truss Attachment Pre-assembly

Mast Clamp and Boom Truss Attachment Pre-assembly

We also pre-assembled things like the Mast Clamp and the Boom Truss Clamp during the parts inventory process.

Boom Assembly

Boom Assembly Details

Boom Assembly Details

The first step in assembling the antenna boom was to arrange all of the boom segments in the correct order and confirm their front/back orientation. This took some time to get right on the first of the four antennas. Each Boom segment was marked with the Sharpie to indicate its location and orientation in the final assembly.

We also installed the T-Brace Clamp to attach the rear of the antenna to the H-Frame’s T-Brace. It’s essential to do this step before assembling the Boom as the clamp cannot be attached once the antenna’s elements are in place. The correct location for the clamp was established via a careful measurement and the location was marked on the boom using the Sharpie.

Assembled Boom

Assembled Boom

The next step was to assemble the boom sections paying careful attention to the markings made earlier. We did not tighten any of the bolts that hold the boom sections together at this stage to allow us to re-clock each boom section for the best alignment of the elements later. A generous coat of NOALOX was used at the joint of the two largest diameter Boom sections to facilitate easier assembly and potential re-clocking later. NOALOX was also used on all bolts to provide anti-seize lubrication.

Once the boom is assembled, a 40-foot tape measure is used to carefully confirm that all of the holes for the elements are in the correct location. The Dimension Sheet is used as a reference to check and confirm that all measurements are correct before installing the Elements. This is also a good time to measure and carefully mark the location of the center of the Mast Clamp on the Boom.

The eye bolts that attach the Boom truss cable are also installed at this time.

Element Installation

Element Installation Details

Element Installation Details

Next came the installation of the elements. We began with the Horizontal reflector and worked towards the front of the antenna. The elements are held in place with insulated buttons and stainless locks. The elements are first installed in the correct location and carefully centered using a steel ruler. Vise-grip pliers are then used to hold the element in its centered position while the M2 supplied tool is used to push the lock on the opposite side of the element. The center is next checked again and if all looks good, the second lock is installed. This process is continued until all of the elements are in place. We pay careful attention to the markings on each element as part of the installation procedure to ensure that all of the elements are in the correct location on the boom.

H-Element Installation Complete - Ready for V-Element Installation

H-Element Installation Complete – Ready for V-Element Installation

Once all of the elements are in place, the antenna is rotated 90 degrees to enable boom adjustments to align the elements. It is common for the boom sections to be misaligned a bit after the initial assembly. A combination of clocking each boom section either a bit one way or the other or sometimes removing the bolts holding two sections together and turning them 180 degrees relative to each other will create a perfect alignment of the elements. Once this is done, all of the bolts that hold the Boom sections together are fully tightened taking care not to distort or crush the Boom tubes.

The same installation process is repeated for all of the vertical elements.

Driven Element Assembly

Feedpoint Assemby

Feedpoint Assembly

The Driven Element feed point blocks are installed next. The mounting screw and the Allen screws in the Shorting Bars all receive a light coat of Blue Locktite thread locker prior to installation.

Next, we loosely install the blocks in their correct location on the Boom and then install the Shorting Bars loosely on the Feed Point Block and Driven Element. Once these parts are in place, the screen that holds the Block to the Boom can be tightened fully, guaranteeing a perfect alignment of all of the parts.

The next step was to accurately set the spacing between the Feed Point Block and each shorting bar. I used a dial caliper to do this accurately but it can also be done with the careful use of a metal machinist’s or similar ruler.

The final step for each feed point was to install the 1/2 wave Coax Balun to the Feed Point Block. Be careful not to overtighten the coax connectors. Just make them snug and you are set. The supplied cable ties are used to secure the Balun to the boom.

The same steps are repeated for the Vertical feed point. It’s a good idea to install connector dust caps on the feed point Block connectors to keep them clean and dry prior to installation.

H and V Feedpoint Orientation

Vertical and Horizontal Feedpoint Orientation

It is critical that the relative orientation between the Horizontal and Vertical Feedpoint Blocks be the same on all four of the antennas in the array. If this is not the case, the pattern of the array will be upset which will have a major negative effect on the array’s performance.

Mast Clamp and Boom Truss

Mast Clamp Installation

Mast Clamp Installation

The Mast Clamp assembly is installed next using the center mark placed on the Boom earlier. I also marked the backside of the Mast Clamp plate to show its center to make lining things up easy. The clamps should be oriented according to the H-frame mounting diagram (show at the front of this article).

Boom Truss Assembly

Boom Truss Assembly

The final step in the assembly process is the assembly of the Boom Truss. The 2MXP28 Yagi is supplied with a Phillystran cable. The height of the Boom Truss will be set later when the antennas are attached to the H-frame so we just installed both ends of the Phillystran cable to the Eye Hooks installed in the Boom. The connections are made using the supplied Strain Relief Loops and small cable clamps. A drop of oil on each nut helps things go together smoothly.  We had some Phillstran cable end caps so I installed them on the Phillystran cable ends to protect against water ingress. The turnbuckles, remaining clamps/strain reliefs, end caps, and truss clamp assembly were stored in a plastic Ziploc bag and cable-tied to the Boom to be installed later when the antennas are attached to the H-frame.

Final Details…

Completed 2MXP28 Antenna Ready for Installation

Completed 2MXP28 Antenna

It’s a good idea to give everything one last go-over now that the antenna is complete. All bolts and screws are checked for tightness, the Elements are all confirmed to be in the right locations, and the feed point assemblies are given a final check.

Four 2MXP28 Antennas Ready for Installation

Four 2MXP28 Antennas Ready for Installation

Our EME project involves the assembly of four of these antennas with a total of 112 elements! It took me about 3 days to assemble each antenna (working about 3-4 hours each day). We stored the antennas on our deck to make space in our shop as we went. The antennas are well supported using low saw horses and woodblocks so as not the bend the Booms or the Elements.

The next step in our project will be to assemble and test the Elevation Rotator system. You can read more about our EME station project via the links that follow:

If you’d like to learn more about How To Get Started in EME, check out the Nashua Area Radio Society Teach Night on this topic. You can find the EME Tech Night here.

Fred, AB1OC

Tech Night – VHF+ Weak Signal Stations Part 1 (Intro and 6 Meters)

Tech Night - VHF+ Weak Signal Stations Part 1 - Overview and 6 Meters

Tech Night – VHF+ Weak Signal Stations Part 1 – Overview and 6 Meters

We recently did a Tech Night on building and operating VHF+ stations as part of the Nashua Area Radio Society’s educational program. I wanted to share the presentation and video from this Tech Night so that our readers might learn a little more about how to get started and build their own VHF+ Weak Signal Station.

There is a lot to this topic so we’re going to cover it with two Tech Night presentations. The first one in the series is included here and it provides an Introduction to the VHF+ topic along with details on building and operating a station for the 6 Meter Band.

July 2020 Tech Night Video – VHF+ Weak Signal Stations Part 1 – Introduction and 6 Meters

You can view this Tech Night session via the video above. Here’s a link to the presentation that goes with the video. You can learn more about the Nashua Area Radio Society’s Tech Night program here.

We have built a number of stations and antennas for the VHF+ Bands (6 Meters and above). Here are some links to articles about those projects and our operations on the VHF+ Bands here on our Blog:

Fred, AB1OC
